Three-Way Control for Navigation & Anchor Lights
The SN Yacht Products Marine 19mm Push Button Nav/Anchor Switch is purpose-built for boaters who demand precision, durability, and clean panel integration. With its unique three-way On/On/Off functionality, this switch gives you full command of your navigation and anchor lighting from a single, compact control point.
How It Works
Position 1 (Nav + Anchor): Activates both navigation lights and anchor light simultaneously — ideal for underway operation in low-visibility conditions.
Position 2 (Anchor Only): Isolates the anchor light for use at rest, keeping your vessel properly lit at anchor without activating nav lights.
Position 3 (Off): Cuts all connected lighting circuits cleanly.
Built for the Marine Environment
Constructed with a stainless steel face and IP67-rated waterproof sealing, this switch is engineered to withstand saltwater spray, UV exposure, and the vibration demands of life on the water. The integrated blue/red LED indicator gives you instant visual confirmation of switch state — even in bright sunlight or at night.
Key Features
- 19mm panel mount — fits panels up to 3/8" thick
- On/On/Off three-way functionality
- Blue/Red LED dual-color indicator light
- IP67 waterproof rated
- Stainless steel construction
- Pre-wired with color-coded leads for easy installation
- Designed specifically for navigation and anchor light circuits
- Backed by the SN Yacht Products warranty
Specifications
-
Diameter: 19mm
-
Voltage: 12V DC
-
Function: On/On/Off (Momentary/Latching)
-
LED Color: Blue / Red
-
Waterproof Rating: IP67
-
Panel Thickness: Up to 3/8"
-
UPC: 198168798928
